Antec NE1200P AU, 1200W, 80 PLUS Platinum, ATX 3.1, PCIe 5.1 (12V-2x6), Full Modular, Active PFC, 120mm FDB Fan, 10Y Warranty

Antec NE1200P AU
Introducing the NeoECO Platinum ATX3.1 power supply, crafted to deliver exceptional performance and rock-solid stability for gamers and enthusiasts. Featuring next-generation ATX 3.1 and PCIe 5.1 support, high-quality Japanese capacitors, and 80 PLUS® Platinum efficiency, it ensures outstanding and consistent power delivery. The PhaseWave™ design provides smooth, reliable output, while the 120 mm FDB silent fan delivers efficient, quiet cooling. Its fully modular design allows for easy cable management, and the Zero RPM Manager intelligently controls fan operation, activating it only when needed to balance silent performance with optimal cooling. Backed by the CircuitShield™ suite of industrial-grade protections, the NeoECO Platinum ATX3.1 is a powerful, efficient, and dependable choice for modern PC builds.
SPECIFICATIONS
Model NE1200 PLATINUM ATX3.1
Safe Model X8000A589EU-25
Type ATX 12V 3.1
Dimension 140(L) * 150(W) * 86(H)
Modular Full-Modular
Warranty 10 years
Input Voltage 100V-240V
Input Current 15A-7.5A
Input Frequency Range 50Hz-60Hz
PFC Active PFC
Power Good Signal 100-150ms
Protection OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
Output Capacity 1200W
Operation Temperature 0~40°C
Regulatory cTUVus / TUV / CB / RCM / CE / FCC /
BSMI / 3C / UKCA / ICES
Fan 120mm FDB Silent Fan
Certifications 80 Plus Platinum
Connector
1 x 24(20+4)pin MB
1 x 16(12+4)pin PCIE 5.1 12V-2x6
2 x 8(4+4)pin CPU
3 x 8(6+2) Pin PCI-E
9 x SATA
3 x Molex
UPC
0-761345-20215-2 NE1200P AU
0-761345-20217-6 NE1200P EC
0-761345-20218-3 NE1200P GB
0-761345-20219-0 NE1200P JP
0-761345-20220-6 NE1200P US
